Specifications:

Nominal Impedance (Passive): 8 ohms

Nominal Impedance (Bi-Amp): LF - 8ohms, HF - 8ohms

Sensitivity:

Passive: 100dB / 1W / 1M

Bi-Amp:  Low Frequency: 103dB / 1W / 1M

                High Frequency: 110dB / 1W / 1M

Max. SPL: 133dB (RMS) 139 (PEAK)

Cover Range (H × V): 100° × 55°

Connectors: 2 × NL4 Socket

Power Handling:

Passive/Full Range: 800watts Program

Bi-Amp:  980watts Program

                Low Frequency: 800watts Program

                High Frequency: 180watts Program

Physical

Hanging: 15 × M8 Hanging points,

Wall Mount: 1 × 35mm Bracket Dual Angle seat (additional dual safety rigging points required)

Carry: 2 × Side Handles

Box Material: 18 mm plywood, CNC manufacturing, high density poplar plywood

Paint Processing: Waterproof and wear-resisting paint compound

Un- Packed Dims (cm): 69.5H x 44.8W x 40.8D

Net Weight (kg): 25kg
