iPhos reserves the right to change the specifications without prior notice.
Electrical and Light Source:
Input Voltage, 90-245V AC-50/60Hz
Max Power Consumption: 36W

Pattern Parameters and Output:
4 x Bubbles (12W)
3 x Lines (9W)
3 x Magic balls (9W)
16 x Laser Images (30mW)

Control:
Control Protocol: DMX512
Number of DMX Channels: 9
Fixture Connection: IEC Power in, DMX Data in/out.
Control Mode: DMX, Stand Alone, Sound-Active

Optical System:
Dimmer: 0-100% Linear dimming, high speed, flicker-free driver chip.
Strobe: 0-20Hz

Environment:
Dry: Indoor Use Only
Ingress Protection Rating: IP20
Operation Temperature:-10'C - +40'C

Physical:
Dimensions (L*W*D): 255*240*122mm (Including Brackets)
Packing Size: 263*232*215mm
Net Weight: 2kg
Shipping Weight: 2.2kg
Housing: Mild Steel
Cooling: Fan Cooling
